Monitor Samsung DB43J



  • Professional-grade, cost-effective display solution that supports 16/7 operation and 300-nit brightness
  • Enhanced graphic performance and content security within a powerful Tizen 3.0 OS
  • Simplified content management with built-in Wifi and an easy-to-use mobile application



Specs



Panel

  • Diagonal Size43″
  • Type60Hz D-LED BLU
  • Resolution1920*1080 (Full HD)
  • Pixel Pitch(mm)0.16333(H) x 0.49005(V)
  • Active Display Area(mm)940.89(H) x 529.25(V)
  • Brightness(Typ.)300 nit
  • Contrast Ratio3000:1
  • Viewing Angle(H/V)178:178
  • Response Time(G-to-G)8ms
  • Display Colors16.7 M
  • Color Gamut72%
  • Haze2%

Display

  • Dynamic C/RMEGA
  • H-Scanning Frequency30 ~ 81kHZ
  • V-Scanning Frequency48 ~ 75HZ
  • Maximum Pixel Frequency148.5MHz

Sound

  • Speaker TypeBuilt in Speaker(10W + 10W)

Connectivity

Input
  • RGBN/A
  • VideoHDMI 1.4 (2), DVI-D
  • HDCPHDCP 2.2
  • AudioStereo Mini Jack, DVI/HDMI/Audio(Common)
  • USBUSB 2.0 x 1
Output
  • RGBN/A
  • VideoN/A
  • AudioStereo Mini Jack
  • Power OutN/A
  • External ControlRS232C(in/out) thru stereo jack, RJ45
  • External SensorIR
  • TunerYes(only for NA)

Power

  • TypeInternal
  • Power SupplyAC 100 – 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption
  • Max[W/h]99
  • Typical[W/h](W/W)67, (US)38, (KR)67
  • BTU(Max)337.6
  • Sleep modeless than 0.5W
  • Off mode0

Mechanical Specification

Dimension (mm)
  • Set985.5 X 574.8 X 73.4
  • Package1099 X 672 X 156
Weight (kg)
  • Set7.9
  • Package11.6
  • VESA Mount (mm)200*200mm
  • Mounting HoleN/A
  • Protection GlassN/A
  • Stand TypeN/A
  • Media Player Option TypeN/A
  • Bezel Width (mm)17.3(Top), 18.3(Bottom), 21.3(Side)

Operation

  • Recommended Usage Hours16/7
  • Operating Temperature0.0  ℃  ~   40.0   ℃
  • Humidity10.0  %  ~   80.0   %

Feature

  • Key FeaturesLight Signage with Built-in MagicInfo S5, SSSP 5.0
  • Special FeaturesH/W : Super Clear Coating, Temperature Sensor, Pivot Display, Button Lock, Clock Battery(168hrs Clock Keeping), Built in Speaker(10W x 2), WiFi Module Embedded S/W : Magic Clone(to USB), Auto Source Switching & Recovery, Image Rotation, RS232C/RJ45 MDC,Plug and Play (DDC2B), Built In MagicInfo Player S5, Firmware Update by Network
Internal Player
  • ProcessorCoretex A72 1.7GHz Quad-Core CPU
  • On-Chip Cache MemoryL1 Instruction Cache : 48KB L1 Data Cache : 32KB L2 Cache : 2MB
  • Clock Speed1.7GHz Quad-Core CPU
  • Main Memory Interface2.5GB LPDDR4 1400MHz 64bit
  • Graphics2D & 3D Graphic Accelerator Data Format : 32bpp Graphic resolution : 1920×1080 Output resolution : 1920×1080
  • Storage (FDM)8GB (3.88GB Occupied by O/S, 4.12GB Available)
  • MultimediaVideo Decoder – MPEG 1/2/4, H.263, H.264/AVC – UHD H.264/AVC, VC-1, AVS/AVS+, MVC – VP8, VP9, HEVC, JPEG Audio DSP(Decoder) – MPEG, AC3, AC4, DD, MP3 and etc
  • IO PortsUSB 2.0
  • Operating SystemTizen 3.0 (VDLinux)

Certification

  • Safety– CB (Europe) : IEC60950-1/EN60950-1 – CCC (China) : GB4943.1-2011 – PSB (Singapore ) : PSB+IEC60950-1 – NOM (Mexico ) : NOM-001-SCFI-1993 – IRAM (Argentina ) : IRAM+IEC60950-1 – SASO (Saudi Arabia ) : SASO+IEC60950-1 – BIS(India) : IEC60950-1 / IS13252 – NOM(Mexico) : Tunerless : NOM-019-SCFI-1998 – KC(Korea) : K 60950-1 – EAC(Russia) : EAC+IEC60950-1 – INMETRO(Brazil) : INMETRO+IEC60950-1 – BSMI(Taiwan) : BSMI+IEC60950-1 – RCM(Australia) : IEC60950-1/AS/NZS 60950-1 – CSA (Canada) : cUL – UL(USA) : cUL60950-1 – TUV (Germany) : CE – NEMKO (Norway) : CE
  • EMC– FCC (USA) Part 15, Subpart B Class A – CE (Europe) : EN55022:2006+A1:2007, EN55024:1998+A1:2001+A2:2003 – VCCI (Japan) : VCCI V-3 /2010.04 Class A – KCC/EK (Korea) : Tunerless : KN22 / KN24 – BSMI (Taiwan) : CNS13438 (ITE EMI) Class A / CNS13439 (AV EMI) / CNS14409 (AV EMS) CNS14972 (Digital) – C-Tick (Australia) : AS/NZS CISPR22:2009 – CCC(China) :GB9254-2008, GB17625.1-2012 – GOST(Russia/CIS) : GOST R 51317 Series, GOST 22505-97, EN55022:2006+A1:2007, EN55024:1998+A1:2001+A2:2003

Accessory

  • IncludedQuick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote Controller, Batteries, RS232C(IN) adapter
Optional
  • StandN/A
  • MountWMN4070SE
  • SpecialtyN/A

Media Player

Media Player
  • Media PlayerSBB (Not attatchable)
