Apart P60DT-BL

6.5″ two-way, pendant loudspeaker, black

     P60DT-BL
     P60DT-W

The Apart P60DT 6.5″ two-way, pendant loudspeaker brings an exceptional dispersion to areas and rooms with high-ceilings or large open spaces, while offering a clear speech and musical purity. Available in black and white, Apart P60DT is suitable for a wide range of background and foreground sound applications. The dual Gripple™ wire suspension system, euroblock in/out connector, loudspeaker cables and 70/100 volt power rotary with 16 ohms connectivity can be hidden after installation by the innovatively designed end-cap. The attractive aesthetics and ease-of-installation make this product an industry standard.

height 265 mm width 276 mm
loudspeaker system 2-way woofer size 6.5 inch
woofer cone material coated paper tweeter size 1 inch
mounting system dual Gripple wire suspension system 100V transformer power taps 60 – 30 – 15 – 7.5 watts
70V transformer power taps 60 – 30 – 15 – 7.5 – 3.75 watts impedance (ohms) 16
low impedance dynamic power 120 watts low impedance RMS power 60 watts
SPL 1W/1m 91 dB max SPL 1m 110 dB
frequency response 65 – 20K Hz main construction material ABS plastic
grille main material steel IP rating indoor use only
Horizontal dispersion angle 1000 Hz 180° Vertical dispersion angle 1000 Hz 180°
